Nano Bubble Generator 1.5 HP
- Oxygen input
- Up to 2 LPM
- Power
- 1.5 HP, 3-phase, 440 V
- Connections
- 1–1.5 inch typical
Full specifications
Pump and motor
- Pump model
- CRI MHC series
- Pump type
- Stainless-steel horizontal multistage centrifugal pump
- Power rating
- 1.5 HP, 3-phase, 440 V
- Motor
- Copper winding, thermal protection, Class F insulation, IP44 enclosure
- Maximum liquid temperature
- +65 °C
- Maximum suction lift
- 1.5 m
- Operating ambient temperature
- Up to +40 °C
Oxygen input and gas handling
- Oxygen input capacity
- Up to 2 LPM
- Compatible with
- PSA oxygen concentrator or oxygen cylinder
- Mixer
- Stainless-steel gas–liquid mixer
Nano-bubbles
- Bubble size
- Typically under 100 nm
- Duty
- Continuous aeration in aquaculture and water treatment
Connections
- Inlet and outlet
- Made to order; commonly 1–1.5 inch
Applications
- Aquaculture ponds
- Hydroponics and horticulture fertigation
- Small-to-medium wastewater aeration units
- R&D and pilot-scale water systems
